Air-flow Dryer

Brief Introduction of Air-flow Dryer:
The air-flow dryer is the latest drying equipment which our company has studied successfully. It can dry the materials mainly using the hot wind produced by the hot-blast stove; the dryer is applied to the material in dispersed state which contains high moisture humidity, such as the saw dust, grain or straw.

If the moisture is very high and the output demand is very big, we can use the two drier together, the material can lose a lot of moisture through the first outlet of the first dryer.

Characteristics of Air-flow Dryer
High drying strength, as the materials highly decentralized in the airflow, all surface area is the drying effective area.
Large handling capacity, high thermal efficiency. When dry the unbound water, the thermal efficiency can reach 60%.
The drying time is short. Simple structure, require the small installation space, very easy to install and repair.

Specification of Air-flow Dryer:

Model	Evaporation (T/H)	Power (KW)	Feeder Power (KW)	Noise	Input Moisture	Final moisture	Temperature
							Input	Outlet
QHG219X4	0.25	7.5	1.1	80 decibel	below40%	8-12%	150-500	60-90
QHG330×4	0.3	22	1.1	80 decibel	below40%	8-12%	150-500	60-90
QHG550×4	0.4	30	1.5	80 decibel	below40%	8-12%	150-500	60-90
QHG650×4	0.5	37	1.5	80 decibel	below40%	8-12%	150-500	60-90
QHG750×4	0.7	45	2.2	80 decibel	below40%	8-12%	150-500	60-90
QHG1000×4	1.0	55	3	80 decibel	below40%	8-12%	150-500	60-90
