Sawdust Pellet Mill

The brief introduction of Sawdust Pellet Mill
There are three kinds of Sawdust Pellet Mill , also called the pellet machines, or the pellet press in the China market now. One is the flat die pellet mill SKJ series, with long history; The other is the ring die pellet mills HKJ series with high output; Another is the efficient pellet mill JK series combined the advantages of the flat die and ring die pellet mills.
The XGJ and SK Sawdust Pellet Mill machine are applied to the materials with low adhesiveness and low shaping, such as the rice husk, sunflower husk, peanut shell and other fruit shell; branch, trunk, bark and other wood waste; a variety of crop straws; rubber; cement, ash and other chemical materials. It is the ideal pressing shaping equipments with low investment and high profit.

Feature of Sawdust Pellet Mill
1. Efficient centrifugal sawdust pellet mill is unique designed pellet machine, which combined the advantage of both horizontal ring die pellet mill and flat die pellet mill.
2. Because of the high pressure and stable operation, our sawdust pellet mill can make good density pellets without bond. The materials that can be used for making pellets by wood pellet machine are as follows:
Coarse fiber: wood sawdust, corn stalk, rice husk, cotton stalk, weeds, crop straw, paper, plastic, cocopeat, bran, home wastage, factory reject and so on.
3.Our efficient centrifugal sawdust pellet mill has lubricanting System so it is also suitable for long time working without stop
4. Double layer ring die has long lifetime so that we can save cost greatly.
5.Efficient centrifugal sawdust pellet mill is hot selling all over the world. It is our patent for biomass energy pellet making machine.

The parameter and advantages of SK series Sawdust Pellet Mill

Model	Output(kg)	Power(kw)	Pellet size(mm)	Weight(kg)	Dimension(mm)
SK2-120	20-40	3-4	4-6	50	1150*300*550
SK2-150	30-50	7.5-4	4-8	150	1260*400*650
SK2-200	50-100	11-4	4-6	200	1300*500*850
SK2-250	100-300	15-4	4-6	500	1400*600*1000
SK2-280	200-400	22-4	4-6	650	1760*670*1600
SK2-300	300-500	30-4	4-8	760	1860*670*1600
SKJ3-350	300-600	37-4	4-10	2200	1900*850*1750
SKJ3-450	500-800	55	4-10	4300	2300*1100*1900
SKJ3-550	1000-1500	90-6	4-12	5500	2350*1000*2050
SKJ3-800	1500-2500	130-160	4-12	6800	3200*1235*2700
SKJ4-1200	3000-5000	280-320	4-15	19000	3800*1700*4200

The parameter and advantages of XGJ series Sawdust Pellet Mill
Efficient pellet mill special for biomass such wood, rice husk etc

Model	Power (kw)	Pellet Size (mm)	Output (kg/h)	Dimension (mm)	Weight (kg)
XGJ 550	75	4-10	700-1000	2630*100*2400	5800
XGJ 560	90	4-10	1000-1500	2600*1300*2300	6100
XGJ 580	160	4-10	1500-2000	2900*1300*2400	7000
XGJ 850	220	4-12	2000-3000	3300*1400*3100	14500
XGJ 880	315	4-12	3000-4000	3800*1680*3400	18000
XGJ 1050	365-450	4-30	5000-6000	4200*1860*3600	24000
XGJ 1250	550-660	4-30	7000-8000	4600*880*3800	32000
