Household Waste Pellet Mill
Brief Introduction of Household Waste Pellet Mill
The series Household Waste Pellet Mill are flat die type, with two rollers, three rollers or four rollers.
This Household Waste Pellet Mill can make the organic fertilizer pellets from animal manure, household waste, agri-waste or other organic elements, or make the compound fertilizer from oulopholite, calcium, potassium or other elements.
During making pellets, keep the nutrient component and microbe in the raw materials under low temperature.
Meanwhile the Household Waste Pellet Mill also can make the fuel pellets for heating from soft sawdust, agri-stalks or agricultural straw & grass.
Features and Functional of Household Waste Pellet Mill
1. Household Waste Pellet Mill is best selling now for home use or to do trail experiment. it can press 2-8mm diameter biomass fuel pellet, animal feed and fertilizer pellets , raw biomass materials can be waste from sawdust, rice husk, agricultural stalk, straw, peanut shell, sun flower, paper ect ,animal feed materials can be grain, soybean, maize ect, fertilizer materials can be animal manure and so on.
2. Household Waste Pellet Mill can press high density pellets , for biomass , density can reach 1.1-1.4ton/m3, diameter can be adjusted from 2-8mm , there is knive installed nearby the outlet door, which can adjust pellet length.
3. Household Waste Pellet Mill adopts Germany high technology ,which is our national patent product. the flat die pellet machine has the unique advantages to enlarge flat die diameter, so roller assemble and bearings are enlarged too, which can produce higher pressure than ring die pellet machine.ring die pellet machine inside ring die is restricted by its diameter, its roller can not be enlarged enough, bearing room is smaller , so the assemble bearing are not strong enough to bear large pressure.
4. Household Waste Pellet Mill especially for crude fiber biomass materials, its adhesive is very low, needs high pressure to press high density pellets, for biomass, flat die wood pellet machine is more fit .for small pellet machine we have special price now .
5. when Household Waste Pellet Mill works, it is flat die rotates and then take rollers work, but the whole roller assemble is stable . in this way will keep all materials piles up in the center of die , increase machine capacity and pelletizing efficiency .
6. Household Waste Pellet Mill can make biomass pellets for burning and make animal feed, fertilizers for farm use. the engine can be installed by both el motor or diesel or connect with PTO tractor .very easy to operate .
7. Household Waste Pellet Mill is very hot selling more than 30000sets per year , greatly welcome all friends to ask me for details. We have big discount at this moment .
Technical Parameter of Household Waste Pellet Mill:
Model |
Power (KW) |
Capacity(KG/H) |
Pellet Diameter (MM) |
SKJ150 pellet mill |
7.5 |
50-150 |
2.5-4 |
SKJ200 pellet mill |
11 |
150-300 |
2.5-6 |
SKJ250 pellet mill |
15 |
200-400 |
2.5-6 |
SKJ280 pellet mill |
22 |
300-600 |
2.5-8 |
SKJ300 pellet mill |
30 |
400-800 |
2.5-8 |
Model |
Power (KW) |
Capacity(KG/H) |
Pellet Diameter (MM) |
SKJ2-350 pellet mill |
37 |
500-1000 |
3-8 |
SKJ2-450 pellet mill |
45 |
800-1200 |
3-8 |
SKJ3-350 pellet mill |
37 |
600-1000 |
3-8 |
SKJ3-450 pellet mill |
45-55 |
1000-1500 |
3-8 |
SKJ3-550 pellet mill |
75-90 |
2000-3000 |
3-10 |
SKJ3-800 pellet mill |
130-160 |
3000-5000 |
3-10 |
SKJ4-1200 pellet mill |
280-320 |
5000-8000 |
3-10 |
